Aluminium Garden Side Gate: Flat Top Vertical Infill & Fully Boarded in Black or Grey

Name: Aluminium Garden Side Gate: Flat Top Vertical Infill & Fully Boarded in Black or Grey
SKU: p25210
Rating: 4.8 (38 reviews)

Product ID: p25210 | RGL

View All Product Information

Garden Side Gate Flat Topped with Vertical Infill

Aluminium Garden Side Gate: Flat Top
Vertical Infill & Fully Boarded in Black or Grey

Secure, low-maintenance privacy and instant curb appeal.

Part of the premium RMG001PG series, this fully boarded aluminium garden gate offers a modern, highly secure solution for any home. Manufactured from heavy-duty aluminium with a vertical infill, this gate combines elegance with zero maintenance and long-lasting performance.

Key Features:

Colour Options: Available in Jet Black (RAL 9005) and Anthracite Grey (RAL 7016). Looking for a bespoke colour? As pricing depends on the specific dimensions of your gate, please contact our support telesales team to request a custom quote.
Full Privacy: Solid, fully boarded vertical infill provides complete privacy for your outdoor space.
Durable Construction: High-strength aluminium ensures weather-resistant, long-lasting performance without warping or rotting.
Low Maintenance: No painting, staining, or oiling required. Simply wash with soapy water.
Easy Installation: Universal opening direction (left or right, inward or outward).
Eco-Friendly Materials: Infinitely recyclable aluminium construction.

Included Hardware:

1 x Pedestrian Gate.
2 x Adjustable wall-mounted hinges.
1 x Floor-mounted hinge.
1 x Pair of gate handles.
1 x Euro barrel lock with 3 keys.
1 x Full-length lock keep.

Choose from an expanded range of standard sizes or opt for our custom width reduction service. See our "How to Choose the Right Gate Size" guide below.

How to Choose the Right Gate Size:

Step 1: Decide How You Want to Hang the Gate

Between Existing Structures (Wall-to-Wall): Fit the gate directly between two existing walls or sturdy pillars.
Wall and New Aluminium Post (25mm, 50mm, or 75mm): Attach a new post to a wall, and hang the gate between the wall and this post.
Between Two New Posts: Install two new aluminium posts, and hang the gate between them.

Step 2: Measure the Opening Width & Height

Measure the Narrowest Point: Always measure your physical opening width and height in millimetres at the absolute narrowest point of the brickwork or gap.
Height Clearance: Ensure your total physical opening height is at least 100mm taller than the gate height you select to allow for proper ground clearance.

Step 3: Account for Posts & Hinge Clearance

The amount of clearance required depends entirely on your installation method:

Between Existing Walls (No Posts): Allow an extra 30mm total width for hinge and lock clearance. (Formula: Total Brickwork Gap = Gate Width + 30mm).
Between Two New Free-Standing Posts: Allow an extra 30mm total width for clearance between the installed posts. You must also add the total width of both posts to your calculation. (Formula: Total Brickwork Gap = Gate Width + 30mm + Post 1 + Post 2).
Wall to Post (Using a single Receiver Post): The hinge and lock clearance allowance slightly reduces when using a wall-mounted post configuration. Allow 20mm total width for clearance, plus the width of your chosen post. (Formula: Total Brickwork Gap = Gate Width + 20mm + Post Width).

Step 4: Check Standard Gate Sizes

Check the dropdown menu to see if a standard size fits your opening exactly. If it does, no custom reduction is required.

Step 5: Calculate Custom Gate Size (If Needed)

If none of the standard sizes fit perfectly, calculate a custom size by taking your measured opening width, allowing 30mm for the hinges, deducting any post widths, and rounding your final calculated width up to the next available standard gate size.

Step 6: Choose your Fit: Standard Size or Bespoke Cut (See Sizing Guide in the Product Description)

If a standard size fits perfectly, simply select 'Standard Size' from the pricing options and leave the Final Gate Width box blank.
If you need a custom width, you must select the 'Bespoke Cut' option from the dropdown menu first, and only then enter your exact calculated width (in mm) into the Final Gate Width box.

Installation Overview

How to Measure & Order

Important Notification on Modifications & Returns:

Please double-check your measurements carefully before completing your order. Modified bespoke sizes and custom colour orders are strictly non-returnable. Please note: Any orders submitted with a custom width entered in the text box, but purchased at the 'Standard Size' price, will be automatically placed on hold until the bespoke cutting fee is settled.

Delivery & Offloading Information

Important Delivery & Access Notice:

To maintain free UK mainland delivery, all gate orders are scheduled via dedicated regional route planning. Any delivery date selected at checkout is strictly an estimate. You will receive email confirmation as your delivery window approaches, followed by a driver text update on the afternoon or evening before arrival.

Standard Sizes (Driveway & Garden Gates): 3 to 4 weeks (15–20 working days).
Custom Width Fabrication & Colours: 5 to 6 weeks to allow for factory workshop adjustments.
Fitted Accessories & Keyed-Alike Services: Please allow an additional 3 to 5 working days.

IMPORTANT OFFLOADING NOTE: Please be aware that metal driveway gates, posts, and substantial garden side gates are heavy, bulky items. Deliveries are made to the kerbside or property boundary only. Due to driver insurance and health & safety regulations, transport drivers are unable to carry units into gardens, rear plots, or domestic garages. Please ensure at least two capable individuals or suitable mechanical lifting equipment are available on-site at the time of delivery to receive and move the goods safely.

Geographical Restrictions: Free delivery applies to mainland England, Wales, and lowland Scotland. We are unable to deliver these units to Northern Ireland, Isle of Wight, Isle of Man, Channel Islands, Scilly Isles, or Scottish Highlands & Islands postcodes (including HS, ZE, KW, IV, PA, PH, KA27–KA28). If your delivery address falls within these areas, please do not complete checkout online—call our sales team directly to discuss alternative transport options.

Feature	Specification
Available Gate Heights	1600mm, 1800mm, 2000mm, or 2200mm
Available Gate Widths	800mm, 850mm, 900mm, 950mm, 1000mm, 1050mm, 1100mm, 1150mm, 1200mm, 1250mm, 1300mm, 1350mm, 1400mm, 1450mm, or 1500mm
Available Colours	Black (RAL 9005) or Anthracite Grey (RAL 7016)
Post Dimensions (Hinge & Receiver)	2100mm (H) x 80mm (D) in 25mm, 50mm, or 75mm Widths
Overall Gate Thickness	55mm
Framework Depth	45mm
Post Wall Thickness	3mm
Heavy Duty Post Wall Thickness	5mm
Wall Hinge Height	40mm
Floor Hinge Height	25mm
Lock Fixture Position	950mm (from bottom of gate to centre of handle)
